Orthopedic Surgical Mini-Horizontal Axis External Fixator

1 / 5

Orthopedic Surgical Mini-Horizontal Axis External Fixator

Customization:	Available
Type:	External Fixation
Application:	Orthopedic

Send Inquiry

Product Description

Basic Information

Model NO.

D500 D501 D502 D503

Material

Steel

Feature

Reusable

Certification

CE, FDA, ISO13485

Group

Adult

Main Material

Aluminum Alloy / Carton / Peek

Product Name

Orthopedic Mini Horizontal External Fixator

Color

Black

Application

Hospital Trauma Operation

HS Code

90189090

Production Capacity

20000 Sets Per Year

Package

Aluminum Case and Carton

Product Description

Application: Used for patients with fractures of limbs.

Suitable for the following situations:

Ordinary open fractures
The contaminated open fractures
Severe comminuted fractures
Fracture of soft tissue serious damage
Temporary fixed Joint ligament which is not stable

Code	Specification
D501	Long 85mm
D502	Middle 75mm
D503	Short 65mm
Schanz Pin
Diameter(mm) 2.0	Specification(mm) screw length/thread length

Material: Aluminum
Surface Finished: Black or according to requirements
Remark: Customized service is available
Certificate: CE & ISO

Key Advantages

Less damage to the blood supply of the bone
Minimal interference with soft-tissue cover
Rapid application in an emergency situation
Stabilization of open and contaminated fractures
Fracture reduction and stable fixation adjustable without surgery
Good solution in situations with high risk of infection or established infection
Bone transport and deformity correction possible

Frequently Asked Questions

Q1: What are the main applications of the Mini Horizontal External Fixator? A: It is primarily used for patients with limb fractures, specifically for open fractures, contaminated fractures, severe comminuted fractures, and soft tissue damage.

Q2: What materials are used to manufacture this fixator? A: The fixator is made from high-quality Steel and Aluminum Alloy, with some components potentially using Carton or Peek depending on specific requirements.

Q3: Is the product certified for medical use? A: Yes, the product holds multiple certifications including CE, FDA, and ISO13485, ensuring it meets international medical safety standards.

Q4: Can the fixator be reused? A: Yes, this model is designed with reusable features, making it a cost-effective solution for hospital trauma operations.

Q5: What sizes are available for this orthopedic device? A: We offer three standard specifications: Long (85mm), Middle (75mm), and Short (65mm), with a 2.0mm diameter Schanz Pin.

Q6: Are customized services available for different colors or finishes? A: Yes, while the standard color is black, customized services are available to meet specific customer requirements regarding surface finishing.
